OT Light Double Dome 3+3

Name: OT Light Double Dome 3+3
Brand: R.S Equipment
Price: 26000.0 INR
Availability: InStock

Price 26000.0 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

OT Light Double Dome 3+3 Specification

Surface Finish
Powder Coated

Usage & Applications
Operation Theatre, Medical Lighting

Weight
Approx. 45 kg

Thickness
3 mm (Dome)

Features
Shadowless Illumination, Adjustable Arm, Energy Efficient

Mounting Type
Ceiling Mounted

Pole Type
Ceiling Mounted

Product Type
OT Light Double Dome

Rated Power
80/80 W

Length
30-32 Inch (Dome Diameter)

Voltage
220-240 V AC

Lighting
LED

Input Voltage
110-240 V

Working Temperature
-10 to 50 C

Rated Current
0.4 A

Socket
E27

Color
White

Height
Adjustable up to 2 meters

Material
MS

Backup Operation
Battery backup optional

Arm Movement
360 Swivel

Dimming Control
Yes, continuous

Focus Adjustment
Manual

Illumination Intensity
130000 Lux +/-10% per dome

Number of Domes
Double Dome (3 + 3 Reflector Head)

Light Field Diameter
12-30 cm (adjustable)

CRI (Color Rendering Index)
>90

Remote Control
Optional

LED Life Span
50,000 hours

Power Consumption
160 W (total)

Ingress Protection
IP54

Power Supply Frequency
50/60 Hz

Color Temperature
4000-5000 K

Sterilizable Handle
Provided

OT Light Double Dome 3+3 Trade Information

Minimum Order Quantity
1 Piece

Payment Terms
Cash Advance (CA)

Supply Ability
10 Pieces Per Week

Sample Available
No

Packaging Details
Box Packinh

Main Domestic Market
All India

About OT Light Double Dome 3+3

Double Dome OT Lightin a hospital is a surgical lighting system designed for use in operating theatres, consisting of two dome-shaped light heads that work together to provide bright, shadow-free illumination over the surgical field.

Detailed Description:

Dual Light Heads:
Two dome-shaped units, each containing multiple high-intensity LED or halogen bulbs arranged to provide even, overlapping light coverage.
Shadow-Free Illumination:
The two domes can be positioned independently to eliminate shadows caused by surgeons hands, heads, or instruments.
Adjustable Intensity And Focus:
Brightness can be dimmed to suit different procedures, and beam focus can be altered for deep or surface lighting.

Precision Illumination for Critical Procedures

Delivering up to 130,000 Lux per dome with adjustable field diameters, the OT Light Double Dome 3+3 ensures brilliant clarity and shadow-free coverage during surgical interventions. Its high CRI (>90) facilitates accurate tissue visualization, supporting medical teams in achieving optimal surgical outcomes.

Reliable, Customizable Performance

Designed for versatility, this ceiling-mounted unit enables manual focus, continuous dimming, 360 arm swivel, and height adjustments up to 2 meters. Its energy-efficient LEDs offer a 50,000-hour lifespan, ensuring dependable lighting with minimal maintenance in any operating room.

Hygienic and Flexible Operation Theatre Lighting

The OT Light Double Dome 3+3 comes with a sterilizable handle for safe adjustments during surgery, while its powder-coated, IP54-rated surfaces and easy-to-clean design uphold stringent medical hygiene standards, supporting infection control protocols.

FAQ's of OT Light Double Dome 3+3:

Q: How does the OT Light Double Dome 3+3 ensure shadowless illumination?

A: The light is designed with dual domes and multiple reflector heads in each dome, distributing high-intensity LED light evenly across the surgical field. This structure eliminates shadows caused by staff or instruments, ensuring uninterrupted visibility during procedures.

Q: What applications and environments is this surgical light suitable for?

A: The OT Light Double Dome 3+3 is ideal for operation theatres, general surgical settings, and any medical environments requiring high-intensity, color-accurate lighting. Its robust construction supports a broad range of clinical and surgical applications.

Q: Where is the light typically installed and how is mounting accomplished?

A: This unit is ceiling-mounted, utilizing a pole-type system for stable support. Ceiling installation ensures hands-free operation, optimal positioning, and maximizes available space in the operating room.

Q: What process is involved in adjusting the focus and positioning of the light during surgery?

A: Manual focus adjustment and a sterilizable handle allow surgical staff to easily modify the light's intensity and field diameter (12-30 cm). The arm's 360 swivel and height adjustment enable precise positioning as surgical needs change.

Q: When might the optional battery backup and remote control be beneficial?

A: The battery backup is especially useful during power outages, providing uninterrupted illumination to maintain patient safety. The remote control option enhances convenience by allowing non-contact adjustments of light settings during sterile procedures.

Q: What are the benefits of using LED technology in this OT light?

A: LEDs provide high-intensity, uniform lighting with excellent color rendering while consuming less energy (160 W total). They offer a long operational lifespan (up to 50,000 hours), reducing replacement and maintenance costs compared to traditional bulbs.

Q: How does the equipment support safety and hygiene standards in medical facilities?

A: The OT Light Double Dome 3+3 features a sterilizable handle, powder-coated surfaces, and an IP54 ingress protection rating, ensuring resistance to dust and splashes. These aspects facilitate easy cleaning and uphold rigorous infection control measures in hospitals.
