OT Light Double Dome 3+4

Name: OT Light Double Dome 3+4
Brand: R.S Equipment
Price: 31000.0 INR
Availability: InStock

Price 31000.0 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

OT Light Double Dome 3+4 Specification

Surface Finish
Powder Coated

Thickness
6 mm Reflector Thickness

Weight
28 kg Approx.

Mounting Type
Ceiling Mount

Usage & Applications
Operation Theatre, Surgical Procedures

Pole Type
Ceiling Mounted

Features
Shadowless Illumination, Adjustable Intensity, Sterilizable Handle

Product Type
Double Dome OT Light

Material
Aluminium Alloy

Rated Power
120 W + 160 W

Length
Arm Length up to 1500 mm

Voltage
220 V

Lighting
LED

Input Voltage
AC 220V, 50Hz

Working Temperature
-10C to 50C

Rated Current
1.5 A

Socket
3 Pin

Color
White & Blue

Height
Adjustable

CRI (Color Rendering Index)
>95

Backup Time (with Battery)
2 Hours (Optional)

Light Field Diameter
Minimum 150 mm

Control Type
Digital Touch Panel

Focusing
Manual Focusing

Illumination Intensity
130,000 + 90,000 Lux

Spot Diameter
150 - 300 mm Adjustable

Number of LEDs
54 (Large Dome) + 36 (Small Dome)

Power Consumption
280 W Combined

Colour Temperature
4000 - 5500 K

OT Light Double Dome 3+4 Trade Information

Minimum Order Quantity
1 Piece

Payment Terms
Cash Advance (CA)

Supply Ability
10 Pieces Per Week

Main Domestic Market
All India

About OT Light Double Dome 3+4

Double Dome OT Lightin a hospital is a surgical lighting system designed for use in operating theatres, consisting of two dome-shaped light heads that work together to provide bright, shadow-free illumination over the surgical field.

Detailed Description:

Dual Light Heads:
Two dome-shaped units, each containing multiple high-intensity LED or halogen bulbs arranged to provide even, overlapping light coverage.
Shadow-Free Illumination:
The two domes can be positioned independently to eliminate shadows caused by surgeons hands, heads, or instruments.
Adjustable Intensity And Focus:
Brightness can be dimmed to suit different procedures, and beam focus can be altered for deep or surface lighting.

Advanced Surgical Lighting Precision

The OT Light Double Dome 3+4 delivers outstanding shadowless illumination using a meticulously engineered combination of 54 and 36 high-efficiency LEDs. Its adjustable light field, digitally controlled intensity, and superior color rendering index ensure accurate tissue differentiation. Manual focusing and flexible arm length further enhance adaptability for diverse surgical setups.

Durable and User-Friendly Design

Crafted from powder-coated aluminium alloy, this ceiling-mounted light features adjustable height, up to 1500 mm arm length, and a sterilizable handle. The intuitive digital touch panel streamlines operation adjustments, while optional battery backup maintains operation even during power interruptions, enhancing both convenience and safety in healthcare environments.

Optimal Application for Operation Theatres

With adjustable color temperature from 4000 to 5500 K and a superior CRI (>95), the Double Dome OT Light is ideal for a variety of surgical procedures. Its robust build and precise lighting control support optimal outcomes, making it an essential addition for medical facilities aiming to provide the highest levels of surgical care.

FAQ's of OT Light Double Dome 3+4:

Q: How does the adjustable illumination intensity benefit surgical procedures?

A: The adjustable illumination intensity (130,000 + 90,000 Lux) allows surgeons to tailor the light output to specific needs, reducing eye fatigue and ensuring optimal visibility during intricate operations.

Q: What is the process for controlling the light settings?

A: The OT Light Double Dome 3+4 features a digital touch panel that enables smooth adjustment of intensity, color temperature, and spot diameter. This user-friendly interface allows for quick setting changes even during procedures.

Q: When would the optional battery backup be most useful?

A: The optional two-hour battery backup is crucial during unexpected power outages, ensuring uninterrupted illumination so that surgical procedures can proceed safely without delay.

Q: Where should this double dome OT light be installed?

A: This surgical light is designed for ceiling mounting above operating tables in hospitals or clinics, providing adjustable overhead lighting for optimal coverage during operations.

Q: What materials and features ensure durability and hygiene?

A: Constructed from aluminium alloy with a powder-coated finish, the OT Light has a sterilizable handle to maintain aseptic conditions and features a robust design for long-term reliability in demanding medical environments.

Q: How is focusing and light field adjustment carried out?

A: Manual focusing and an adjustable spot diameter (150-300 mm) allow clinicians to precisely control the light field, adapting easily to various surgical requirements and anatomical areas.

Q: What are the primary benefits of using this OT light in surgical applications?

A: The primary advantages include shadowless, high-intensity, and adjustable illumination, excellent color accuracy (CRI >95), reliable backup power, and ergonomic controls-all contributing to improved surgical performance and patient outcomes.
