OT Light Double Dome 5+5

Name: OT Light Double Dome 5+5
Brand: R.S Equipment
Price: 56000.0 INR
Availability: InStock

Price 56000.0 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

OT Light Double Dome 5+5 Specification

Thickness
2 mm (Dome cover)

Features
Shadowless, Low Heat Generation, Adjustable Focus

Weight
36 kg approx.

Usage & Applications
Operation Theaters, Surgical Illumination

Surface Finish
Powder Coated

Mounting Type
Ceiling Mount

Pole Type
Ceiling Mounted

Product Type
Surgical OT Light Double Dome

Material
ABS & Metal

Rated Power
120W + 120W (Two Domes)

Length
500 mm per Dome

Voltage
220V AC

Lighting
LED

Input Voltage
110-240V AC, 50/60Hz

Working Temperature
10C to 40C

Rated Current
1A

Socket
E27

Color
White/Blue

Height
Adjustable up to 1800 mm

Color Temperature
4000-5000 K

Sterilizer Handle
Provided with autoclavable handle

CRI (Color Rendering Index)
>90

Number of LEDs
54 per dome

Illumination Intensity
1,00,000 Lux + 1,00,000 Lux

LED Life Span
>50,000 hours

Dome Diameter
500 mm each

Power Supply Frequency
50/60 Hz

Focusing
Manual Focusing

Light Field Diameter
12-30 cm adjustable

Power Consumption
120W per dome

Backup Battery
Optional (on request)

Remote Control
Optional

Number of Domes
Double Dome (5+5 Reflectors)

OT Light Double Dome 5+5 Trade Information

Minimum Order Quantity
1 Piece

Payment Terms
Cash Advance (CA)

Supply Ability
10 Pieces Per Week

Delivery Time
5-7 Days

Sample Available
No

Packaging Details
Box Packing

Main Domestic Market
All India

About OT Light Double Dome 5+5

Double Dome OT Lightin a hospital is a surgical lighting system designed for use in operating theatres, consisting of two dome-shaped light heads that work together to provide bright, shadow-free illumination over the surgical field.

Detailed Description:

Dual Light Heads:
Two dome-shaped units, each containing multiple high-intensity LED or halogen bulbs arranged to provide even, overlapping light coverage.
Shadow-Free Illumination:
The two domes can be positioned independently to eliminate shadows caused by surgeons hands, heads, or instruments.
Adjustable Intensity And Focus:
Brightness can be dimmed to suit different procedures, and beam focus can be altered for deep or surface lighting.

Superior Illumination for Every Procedure

The OT Light Double Dome 5+5 delivers bright, uniform, and shadowless lighting, making it perfect for delicate surgeries and extended procedures. With an impressive illumination intensity of 100,000 Lux per dome and manual focus adjustment, surgical teams can achieve optimal visibility, reduce eye strain, and enhance surgical accuracy.

Durability Meets Hygiene

Designed with a powder-coated ABS and metal construction, the OT Light Double Dome ensures long-lasting performance and easy cleaning. Its autoclavable sterilizer handle promotes strict infection control, while the dome's robust build and LED lifespan of over 50,000 hours minimize maintenance for busy operation theaters.

Flexible, User-Friendly Design

Mounted on the ceiling with adjustable height up to 1800 mm, this surgical OT light adapts seamlessly to various procedures. The optional remote control and backup battery add convenience and reliability, ensuring uninterrupted surgical illumination, even during power fluctuations or emergencies.

FAQ's of OT Light Double Dome 5+5:

Q: How does the manual focusing system of the OT Light Double Dome 5+5 enhance surgical performance?

A: The manual focusing feature enables precise adjustment of the light field diameter (12-30 cm), allowing medical professionals to direct intense, shadow-free illumination exactly where it's needed. This flexibility is crucial for procedures requiring concentrated or broad lighting, improving visibility and outcomes.

Q: What benefits does the double dome design with 5+5 reflectors provide in operation theaters?

A: The double dome, each with five reflectors, provides even light distribution and minimizes shadows during surgery. This shadowless effect ensures consistent brightness over the surgical field, enhancing safety and reducing fatigue for clinicians during lengthy procedures.

Q: When should I consider using the optional backup battery for this OT light?

A: The backup battery option is recommended in environments where power supply interruptions are possible. It ensures continuous lighting during critical surgeries, preventing disruptions that could compromise patient safety or procedural outcomes.

Q: Where is the OT Light Double Dome best installed for maximum effectiveness?

A: This light is designed for ceiling mounting in operation theaters. Its adjustable height (up to 1800 mm) and ceiling pole compatibility provide optimal overhead lighting, freeing up valuable floor space and facilitating better workflow in the surgical area.

Q: What process should be followed to sterilize the handle of the OT light?

A: The provided sterilizer handle is autoclavable, which means it can be removed and placed in an autoclave for high-temperature sterilization. This process helps maintain hygienic standards and reduces the risk of infection in sterile surgical environments.

Q: Is the remote control a standard feature with the OT Light Double Dome 5+5, and how does it improve usage?

A: The remote control is an optional accessory. When included, it allows surgical staff to adjust lighting parameters such as intensity and focus without touching the light, promoting hygiene and operational efficiency.

Q: What is the expected lifespan of the LEDs, and how does this benefit daily operation?

A: Each dome contains 54 LEDs with a lifespan exceeding 50,000 hours. This ensures years of consistent, low-maintenance performance, reducing the need for frequent replacements and minimizing downtime in busy healthcare settings.
