OT Light Single Dome -4

Name: OT Light Single Dome -4
Brand: R.S Equipment
Price: 25000.0 INR
Availability: InStock

Price 25000.0 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

OT Light Single Dome -4 Specification

Mounting Type
Ceiling Mounted/Portable

Features
Shadowless Illumination, Adjustable Focus, Low Heat Generation

Surface Finish
Powder Coated

Pole Type
Portable, Ceiling Mounted

Usage & Applications
Operation Theatre, Surgical Procedures

Weight
12 kg Approx.

Thickness
2-3 mm (Housing)

Product Type
OT Light Single Dome 4

Material
Metal/Aluminum Alloy

Rated Power
220W

Length
45 cm (Dome Diameter)

Voltage
230V AC

Lighting
LED-based

Input Voltage
110-240V AC, 50/60 Hz

Working Temperature
10C to 40C

Rated Current
Max. 0.7A

Socket
Standard Electrical Socket

Color
White & Blue

Height
Adjustable up to 2 meters

Electrical Safety Class
Class I

Sterilizer Handle
Detachable & Sterilizable

Power Backup Option
Compatible (Optional Accessory)

Dome Type
Single Dome

Luminance Intensity
1,20,000 Lux (at 1 meter)

Color Temperature
4300K 200K

Average LED Life Span
50,000 Hours

CRI (Color Rendering Index)
>95

Number of LED Bulbs
36 High-Intensity LEDs

Illumination Adjustment
Variable, Step-less (Digital Control)

Arm Movement
360 Rotation

OT Light Single Dome -4 Trade Information

Minimum Order Quantity
1 Piece

Payment Terms
Cash in Advance (CID)

Supply Ability
10 Pieces Per Week

Main Domestic Market
All India

About OT Light Single Dome -4

Single Dome OT Lightis a surgical lighting unit with one dome-shaped light head, designed to deliver bright, focused, and shadow-minimized illumination for operating theatres and minor surgical procedures.

Detailed Description:

Single Dome Design:
One light head containing multiple LED or halogen bulbs arranged to provide uniform illumination over the surgical area.
High-Intensity, Shadow-Reduced Lighting:
Designed to minimize shadows caused by surgical staff or instruments, ensuring a clear view of the operative field.
Adjustable Brightness And Focus:
Allows surgeons to tailor light intensity and beam size to the specific procedure.

High-Intensity, Shadowless Performance

With 36 high-intensity LED bulbs, the OT Light Single Dome-4 delivers 1,20,000 Lux at one meter, ensuring clear, shadow-free illumination essential for delicate surgical tasks. An exceptional color rendering index (CRI) above 95 allows for the accurate distinction of tissues and structures.

Flexible and Reliable Design

Designed for convenience, this OT light offers both ceiling-mounted and portable configurations. Its adjustable dome height (up to 2 meters) and 360-degree arm rotation provide optimal positioning, while sterilizable handles enhance infection control during procedures.

Efficient, Safe, and User-Friendly

The digital, step-less illumination control allows smooth luminance adjustment to suit surgical needs. Combining robust construction with a low heat output and an average 50,000-hour LED life span, this model ensures energy efficiency, reliability, and reduced maintenance over time.

FAQ's of OT Light Single Dome -4:

Q: How do I adjust the brightness of the OT Light Single Dome-4?

A: The brightness can be easily adjusted using its digital control, allowing for step-less, variable illumination to match the requirements of different surgical procedures.

Q: What benefits does the high CRI and precise color temperature offer during procedures?

A: A CRI above 95 and a color temperature of 4300K 200K provide accurate color differentiation, ensuring that surgeons can identify tissues and anatomical details reliably and precisely.

Q: When should I sterilize the detachable handle, and how is it done?

A: Sterilize the detachable handle before and after every surgical use to maintain infection control. The handle is designed specifically for easy removal and can be autoclaved or disinfected according to standard hospital protocols.

Q: Where can this light be installed, and what mounting options are available?

A: The OT Light Single Dome-4 supports both ceiling-mounted and portable pole configurations, making it versatile for use in various operation theatres and clinical settings depending on available infrastructure.

Q: What is the process for switching between portable and ceiling-mounted installations?

A: The light comes with parts and instructions for both mounting types. Follow the manufacturer's guidelines for secure installation and, if needed, engage a trained technician to ensure proper setup tailored to your space.

Q: How does the power backup option enhance usage?

A: A compatible power backup accessory can be connected as an optional feature, ensuring uninterrupted operation during power outages and enhancing safety during critical surgical procedures.

Q: What are the main advantages of using this OT lamp in surgery?

A: Key advantages include superior shadowless illumination, highly adjustable focus and position, minimal heat generation, and a long LED lifespan, all contributing to efficient, safe, and comfortable surgical environments.
