OT Light Double Dome 5+4

Name: OT Light Double Dome 5+4
Brand: R.S Equipment
Price: 50000.0 INR
Availability: InStock

Price 50000.0 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

OT Light Double Dome 5+4 Specification

Pole Type
Ceiling Mounted

Features
Shadowless Illumination, Adjustable Intensity, Sterilizable Handle, Energy Efficient

Mounting Type
Ceiling Mount

Thickness
Body 2 mm (Aluminum Alloy)

Surface Finish
Powder Coated

Weight
23 kg (Approx.)

Usage & Applications
Operation Theater Lighting

Product Type
Operation Theater Double Dome LED Light

Material
Aluminum Alloy and Polycarbonate

Rated Power
120W + 80W

Length
Dome Diameter: 500 mm (Large), 400 mm (Small)

Voltage
220V AC

Lighting
LED

Input Voltage
110V - 240V AC, 50/60 Hz

Working Temperature
-10C to 50C

Rated Current
0.65A (Max)

Socket
E27 (for service socket)

Color
White & Blue

Height
Adjustable, max 2.2 meters from floor

Lifespan of LED
>50,000 hours

Sterilizable Handle
Yes, Removable Type

Noise Level
<35 dB

Light Field Diameter
12-30 cm (Adjustable)

Arm Movement
360 Rotation, Spring Balanced Arm

CRI (Color Rendering Index)
>95

Ambient Light
<1000 Lux

Focusing
Manual Adjust

Number of LEDs
76 (Large Dome) + 48 (Small Dome)

Control Panel
Digital Touch Control

Color Temperature
3800K - 5200K (Adjustable)

Light Intensity
1,20,000 Lux + 90,000 Lux (at 1m)

Power Backup
Compatible with UPS or Battery Backup (Optional)

OT Light Double Dome 5+4 Trade Information

Minimum Order Quantity
1 Piece

Payment Terms
Cash Advance (CA)

Supply Ability
10 Pieces Per Week

Main Domestic Market
All India

About OT Light Double Dome 5+4

Double Dome OT Lightin a hospital is a surgical lighting system designed for use in operating theatres, consisting of two dome-shaped light heads that work together to provide bright, shadow-free illumination over the surgical field.

Detailed Description:

Dual Light Heads:
Two dome-shaped units, each containing multiple high-intensity LED or halogen bulbs arranged to provide even, overlapping light coverage.
Shadow-Free Illumination:
The two domes can be positioned independently to eliminate shadows caused by surgeons hands, heads, or instruments.
Adjustable Intensity And Focus:
Brightness can be dimmed to suit different procedures, and beam focus can be altered for deep or surface lighting.

Precision Lighting for Every Procedure

This double dome OT light ensures high-intensity illumination with natural color rendering, making it ideal for a variety of surgeries. The adjustable light field diameter (12-30 cm) and color temperature give surgeons the flexibility to adapt the light profile for each procedure, while the shadowless design enhances clarity and reduces visual fatigue.

Unmatched Durability and Efficiency

Constructed with aluminum alloy and polycarbonate, this surgical light system offers both robustness and lightweight maneuverability. With LEDs rated for over 50,000 hours and a rated power of just 200W total, the fixture promises long-term energy efficiency, lower maintenance, and reliability even during intensive use. Optional UPS or battery backup ensures confidence during power interruptions.

Ease of Use and Safe Operation

The digital touch panel allows for seamless intensity control and adjustments, while the sterilizable, removable handle meets surgical hygiene standards. The ceiling-mounted spring-balanced arm offers 360-degree rotation and height adjustment up to 2.2 meters, enabling optimal positioning regardless of operating room constraints.

FAQ's of OT Light Double Dome 5+4:

Q: How is the light intensity and field adjustable on the OT Light Double Dome 5+4?

A: The light intensity can be adjusted using the digital touch control panel, and the light field diameter is manually adjustable from 12 to 30 cm, allowing surgeons to fine-tune illumination based on the surgical requirement.

Q: What are the benefits of choosing this double dome OT light for operation theaters?

A: Benefits include powerful shadowless illumination, high color rendering (CRI >95), long LED lifespan (>50,000 hours), flexible positioning, and energy efficiency. It also features a sterilizable handle for infection control and optional battery backup for uninterrupted surgeries.

Q: Where can this OT light be installed, and what is its mounting type?

A: This OT light is engineered for ceiling mounting, making it ideal for operation theaters in hospitals and surgical centers. Its design saves floor space while allowing full mobility and precise positioning over the operating area.

Q: What materials are used in its construction, and how does this affect durability?

A: The system is made from a combination of aluminum alloy (2 mm thick) and polycarbonate. This blend ensures a balance of rugged durability and reduced weight, providing longevity and resistance to operating room conditions.

Q: How does the sterilizable handle contribute to safer surgical procedures?

A: The removable, sterilizable handle allows quick and thorough cleaning, minimizing infection risks and complying with strict hygiene protocols in surgical environments.

Q: When should a facility opt for the optional UPS or battery backup with this OT light?

A: Facilities experiencing frequent power interruptions or needing assured continuous lighting during critical surgeries should integrate the optional UPS or battery backup to maintain consistent operation theater illumination.

Q: What is the process for adjusting the light's focus and positioning during a procedure?

A: The focus is adjusted manually, while the spring-balanced, 360 rotating arm enables effortless dome repositioning and height adjustment up to 2.2 meters, allowing quick modifications during operations without disrupting the sterile field.
