OT Light Double Dome 6+3

Name: OT Light Double Dome 6+3
Brand: R.S Equipment
Price: 58000.0 INR
Availability: InStock

Price 58000.0 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

OT Light Double Dome 6+3 Specification

Weight
Approx. 28 kg

Thickness
Dome Thickness 3 mm

Features
Shadowless design, High-luminance, Cool light effect, Focus adjustment, Long life LED

Pole Type
Ceiling Mounted

Surface Finish
Epoxy Powder Coated

Mounting Type
Ceiling Mount

Usage & Applications
Operation Theatre Illumination

Product Type
OT Light Double Dome 6+3

Material
Aluminum & Polycarbonate Domes

Rated Power
120/85 W (Main/Standby Domes)

Length
Domes: 600mm (Main), 400mm (Satellite)

Voltage
220-240 V AC

Lighting
LED White Light

Input Voltage
220V AC 10%

Working Temperature
-10C to 45C

Rated Current
0.70 A

Socket
Standard Medical Grade

Color
White & Blue

Height
Adjustable, Max. Height 2200mm

Sterilization
Autoclavable Handles

Number of LEDs
54 (Main) + 27 (Satellite)

Illumination Intensity
140,000 Lux (Main), 90,000 Lux (Satellite)

Dimming Range
10% to 100%

Focusing
Sterilizable handle, Manual focus

Noise Level
< 30 dB

Control Mode
Digital Touch Panel

Number of Domes
2 (6-reflector Main, 3-reflector Satellite)

Backup
Optional, with inbuilt Battery (up to 2 hours)

Light Field Diameter
12-28 cm

CRI (Color Rendering Index)
>95

LED Life Span
>50,000 hours

Color Temperature
4000-5000 K

Safety
Overheating, Overvoltage, Overcurrent Protected

Power Consumption
120W (Main), 85W (Satellite)

OT Light Double Dome 6+3 Trade Information

Minimum Order Quantity
1 Piece

Payment Terms
Cash Advance (CA)

Supply Ability
10 Pieces Per Week

Main Domestic Market
All India

About OT Light Double Dome 6+3

Double Dome OT Lightin a hospital is a surgical lighting system designed for use in operating theatres, consisting of two dome-shaped light heads that work together to provide bright, shadow-free illumination over the surgical field.

Detailed Description:

Dual Light Heads:
Two dome-shaped units, each containing multiple high-intensity LED or halogen bulbs arranged to provide even, overlapping light coverage.
Shadow-Free Illumination:
The two domes can be positioned independently to eliminate shadows caused by surgeons hands, heads, or instruments.
Adjustable Intensity And Focus:
Brightness can be dimmed to suit different procedures, and beam focus can be altered for deep or surface lighting.

Exceptional Illumination for Surgical Precision

Designed for critical operation theatre environments, the Double Dome system ensures shadowless, crisp, and cool light with uniform intensity across the surgical area. This enhances visibility for surgeons, reducing eye strain and improving procedure accuracy.

Advanced Controls and User-Friendly Design

A digital touch panel allows granular dimming control and easy adjustment, while the sterilizable, autoclavable handle ensures sterile operation. The dome's height is adjustable up to 2200mm, making it versatile for diverse surgical setups.

Reliable Build and Safety Features

Crafted from aluminum and polycarbonate, the domes are robust yet lightweight. Top-tier safety systems protect against overheating, overvoltage, and overcurrent, ensuring uninterrupted, dependable performance during surgery.

FAQ's of OT Light Double Dome 6+3:

Q: How does the OT Light Double Dome 6+3 benefit surgical procedures?

A: This light delivers high-luminance, shadowless illumination with adjustable intensity, allowing surgeons to see intricate details clearly. Its optimal light field diameter and color rendering improve visual perception, which is essential for accurate and safe surgical interventions.

Q: What is the usage and application area for this OT Light model?

A: The OT Light Double Dome 6+3 is designed exclusively for operation theatre illumination, suitable for all general and speciality surgeries in hospitals, clinics, and advanced medical centres across India.

Q: How is the focusing and sterilization process managed?

A: Focusing can be manually adjusted using a sterilizable handle, and the handle itself is autoclavable, ensuring compliance with strict medical hygiene standards and allowing safe, sterile field adjustments during operations.

Q: What is the process for controlling light intensity and mode?

A: The system features a digital touch panel control for easy adjustment of light intensity, with a dimming range from 10% to 100%. Surgeons can quickly adapt the lighting to procedural needs through the intuitive interface.

Q: When is the backup battery function utilized, and how long does it last?

A: The optional inbuilt battery backup activates automatically during power outages, providing up to two hours of continuous illumination-a crucial benefit for uninterrupted surgeries.

Q: Where should the OT Light Double Dome 6+3 be installed?

A: This unit is designed for ceiling mounting in operation theatres. Its adjustable height and pole type make it suitable for diverse room configurations and ceiling heights up to 2200mm.

Q: What makes the OT Light Double Dome 6+3 a safe and reliable choice?

A: It incorporates advanced safety protections against overheating, overvoltage, and overcurrent, ensuring consistent performance. Its low noise level (<30 dB) and robust construction further enhance reliability and safety in sensitive surgical settings.
